DAF NG DRL unit warm white

Beschikbaarheid: In stock

| ordered before 14:30, shipped today |

DAF NG LED daytime running lights WARM WHITE - LED DRL unit for DAF XF, XG and XG+ - suitable for models from 2021+ - EAN: 6090544022082
DAF NG LED daytime running lights WARM WHITE - LED DRL unit for DAF XF, XG and XG+ - suitable for models from 2021+ - EAN: 6090544022082 DAF NG LED daytime running lights WARM WHITE - LED DRL unit for DAF XF, XG and XG+ - suitable for models from 2021+ - EAN: 6090544022082

€185,00 Excl. VAT €223,85 incl. 21% VAT

Beschikbaarheid: In stock

DAF NG LED daytime running lights WARM WHITE - LED DRL unit for DAF XF, XG and XG+ - suitable for models from 2021+ - EAN: 6090544022082
DAF NG DRL unit warm white

€185,00 Excl. VAT €223,85 incl. 21% VAT

Description

DAF NG DRL unit warm white, year 2021+.

Would you like to replace your original white LED daytime running lights of your DAF NG truck for a warm white colour? Then this DRL set may be the set you are looking for. This set consists of two LED plates with which you can change both the left and right module. You can easily replace the originally mounted lighting for the warm white variant. At the bottom of the page you will find the steps you need to follow. This DRL set is only made for a DAF truck of which the year of manufacture is 2021+. You can install the DRL set in both the XF and XG models with a LED module in the headlights. The set is made to fit a DAF and will therefore not fit in any other brand of truck. The warm white color of the DAF 106 daytime running lights is the same as that of a halogen lamp.

A set consists of two LED plates. Each PCB is equipped with eleven powerful LED's, which will cause the entire module to light up. The LED module is exactly the same as the original mounted one. As a result, replacing the module is done quickly and you do not have to adjust anything in the original lamp. The LED unit is made of high quality material. This guarantees a long service life. In short, by mounting the LED lighting in your DAF you can be sure that you can hit the road well lit. The DAF NG LED warm white daytime running lights do not have an E-mark. That is why you have to reassemble the original one for the MOT.

Other models:

Do you have a DAF truck. But isn't this fitted with the same units shown in picture 2? Or do you just want a different color? View the other available models of DRL units for the DAF truck here:

Edit:

To install the DAF NG DRL unit warm white, you must follow the following steps. The installation of the LED lighting will take approximately one hour per headlamp. Figure 3 shows an example of how the set will eventually light up after installation.

  1. Remove the connector from the existing lighting.
  2. Remove the screws securing the original diode holders.
  3. Remove the diode holders from the cooling plates.
  4. Remove the thermal paste and clean the surface well.
  5. Bring the supplied thermal paste in a thin even layer to the cooling plates where the lamp will be mounted.
  6. Push the diode holder into the thermal paste and secure it carefully with the original screw.
  7. Insert the connector into the new diode holder.
  8. The lighting of your DAF NG is ready for use.

Do you not only want to replace the warm white DRL unit of your DAF NG? But are you looking for more LED lighting that you can mount in or around your DAF? Then take a look at the page DAF lighting.

Specifications

Gewicht 0,165 kg
SKU:

ADL49220

Brand

Voltage

24 volt

Color

Warm white, White

Color LED

3000K – Warm White

Content

1 Set

CAN-Bus

Yes

Material

Plastic

Type of lighting

Daytime running lights

Functions

Daytime running lights, City lights

Cable connection

DAF plug

Number of LED's

11 LED's

Edit

Recessed mounting

Waterproof

Not waterproof

E-mark

No

ADR

No

EMC

ECE R10

EAN

6090544022082

Warranty

1 Year
